Efficient, Hygienic, and Homogeneous Mixing for Modern Process Applications
The Milkon Liquid-Solid Blender is designed for the rapid and uniform dispersion of dry powders into liquid streams. Engineered for continuous and batch processing, it ensures perfect homogeneity and smooth blending without lumps or air entrapment - ideal for dairy, beverage, brewery, food, pharmaceutical, and chemical industries. |
| |
|
|
Applications
- Dairy: Milk Powder Reconstitution, Ice Cream Mix, Whey Solutions
- Beverages : Syrups, Flavours, Juices, Concentrates
- Brewery : Malt Extracts, Additives, Enzyme Solutions
- Food Processing : Sauces, Chocolates, Dressings, Condiments
- Pharmaceuticals : Oral Suspensions, Nutraceuticals, Protein Mixes
- Chemicals & Cosmetics : Detergents, Gels, Emulsions, Creams
|
| |
|
Operating Principle
The Milkon Liquid - Solid Blender uses a Venturi system combined with a high-shear rotor - stator mechanism. Liquid is circulated through the pump, creating a strong suction at the inlet hopper. This suction draws powder into the liquid stream, where it undergoes instant dispersion and homogenization. The result is a smooth, lump - free mixture with consistent texture and quality - achieved in a single pass.
|
|
|
|
|
- Hygienic Design : All product-contact parts are made of AISI 316L / AISI 304L stainless steel with mirror-polished surfaces.
- Efficient Mixing : Achieves complete powder dissolution and uniform blending in minimal time.
- High-Shear Capability : Optional rotor-casing head for emulsification and sheanng applications.
- Easy Cleaning : Fully CIP/SIP compatible; no dead zones or product retention.
- Flexible Configuration: Available as fixed. mobile, or skid-mounted systems.
- User-Friendly Operation: Simple design with low maintenance requirements.
|
Benefits |
- Consistent and homogeneous product quality
- Reduced mixing time and improved process efficiency
- Lump-free dispersion of powders
- Gentle handling of heat-sensitive materials
- Compact design for easy installation
- Energy-efficient and low operating noise
- Blending, Emulsify, Dispersing, Dissolving & reduces particle size
|
|
Technical Specifications |
- Flow Rate : Up to 10,000 LPH
- Solids Capacity : Up to 20% concentration
- Viscosity Range : Up to 10,000 cp
- Mixing Type : Liquid-Solid and Liquid—Liquid
- Construction Material : SS 316 / SS 316L
- Sealing Options : Single / Double Mechanical Seal
- Surface Finish : Mirror Polished
- Connection Type : Tri-Clamp / SMS
- Mounting Options : Skid Mounted / Trolley Mounted
- CIP/SIP : Fully Cleanable & Sterilizable Design
|
| |
Design Options |
- Integrated powder hopper with butterfly or valve control
- Double mechanical seal with flushing system
- Variable frequency drive for speed control
- High-shear stator for emulsification applications
- Custom-built mixing skids with load cells and instrumentation
|
| |
Why Choose Milkon Blenders |
At Milkon Heavy Engineering Pvt. Ltd., we specialize in hygienic, reliable, and energy - efficient process systems. Our Liquid-Solid Blender delivers superior performance with complete powder dispersion, reduced processing time, and consistent results - ensuring your production line remains efficient, clean, and cost-effective. |
| |
|
|
|
| |
|
